It is the popular PMX105 Plasma Cutting Torch. Without HF Ignition, easy to start arc. It is compatible with standard of 85A Plasma Cutting Machine. (i.e. CUT105/125) The Brand of machines would be Rilon, Riland, Jasic, Mitech, Chiry, UNT, Krypton, Longetivity and so on.
Current | 105/125Amp | Gas Flow | 255LPM |
Duty Cycle | 60% | Ignition | Without HF |
Gas | Air/N2 | Post Flow | 120 seconds recommended |
Gas Pressure | 5.0-5.5Bar | Standard Length | 6M |
Position | Code | Ref. | Description |
(带"•” 为标准配置 / With is the standard configuration } | |||
1 | Shield cap;保护帽 | ||
1.1 | 220818 | Shield cap/45A-85A;保护帽Z45A-85A | |
1.2 | 220992 | Shield cap/105A;保护帽Z105A | |
2 | 220798 | Shield cap/Gouging;保护帽/气刨 | |
3 | Tip;喷嘴 | ||
3.1 | ISM0623 | Shield cap PMX105/105P/hand/45A-85A/PRO;保护帽 PMX65/85/手动枪/45A-85A/PRO | |
• 3.2 | ISM0621 | Shield cap PMXM105/hand/105A/PRO;保护帽 PMXM105/手动枪/105A/PRO | |
4 | Outside nozzle ;外喷嘴 | ||
4.1 | IVS0693 | Outside nozzle PMX65/85/105/6 holes;外喷嘴/PMX65/85/105/带短路环/6礼/45-85A | |
♦ 4.2 | IVS0694 | Outside nozzle PMX65/85/105/10 holes;外喷嘴/PMX65/85/105/带短路环/10礼/105-125A | |
5 | Tip;喷嘴 | ||
5.1 | 220941 | Tip/45A;喷嘴45A | |
5.2 | 220819 | Tip/65A;喷嘴65A | |
5.3 | 220816 | Tip/85A;喷嘴85A | |
5.4 | 220990 | Tip/105A;喷嘴 105A | |
6 | Tip;喷嘴 | ||
6.1 | 220797 | Tip/45~85A/Gouging;喷嘴45~85A/气刨 | |
6.2 | 220991 | Tip/105A/Gouging;喷嘴 105AZ气刨 | |
7 | Tip;喷嘴 | ||
7.1 | IVU0653-09 | Tip O0.9mm/PMX105/45A/PRO;喷嘴 O0.9mm/PMX105/45A/PRO | |
7.2 | IVU0653-11 | Tip 01.1 mm/PMX105/65A/PRO;喷嘴 01.1 mm/PMXI05/65A/PRO | |
7.3 | IVU0653-13 | Tip <J> 1.3mm/PMX105/85A/PRO;喷嘴 <J> 1.3mm/PMX105/85A/PRO | |
• 7.4 | IVU0653-15 | Tip <J> 1.5mm/PMX105/105A/PRO;喷嘴 <J> 1.5mm/PMX105/105A/PRO | |
7.5 | IVU0653-18 | Tip <J> 1.8mm/PMX105/125A/PR0;喷嘴 <J> 1.8mm/PMX105/125A/PRO | |
• 8 | IVF3003 | Swirl ring PMX105/105A;涡流环 PMX105/105A | |
9 | 220842 | Electrode;电极 | |
• 10 | IVB0032 | Electrode PMX65/85/105/43.4;m®/PMX65/85/105/43.4 | |
11 | IVZ0694 | Plasma cutting torch head/PMX65/85/105;W离子枪头/PMX65/85/105 | |
11a | IFT0675 | ORING ④ 17x20.6x1.8/RED SILICONE;'。'型圈 17 x 20.6x1.8/红色硅胶 | |
12 | IGV0035-01 | Plasma handle manuale/A seires/red;等离子手工手柄/A系列/红色/高频低频共用 | |
13 | IHJ0722 | Protection part/plasma/yellow;开关保护档片/等离子用/黄色 | |
14 | IHQ0070 | Trigger red;焊枪用开关21.8MM红色 | |
15 | IHJ0893 | Tig joint/small/new type;TIG 用球节套件/小/新式 | |
16 | Cable assembly;电缆组 | ||
16.1 | IVN02010061-300 | Cable assembely/PMX85/105/6M/2 WIRES/separated; * 缆组/PMX85/105/6M/两芯控制线/气电分体 | |
16.2 | IVN02010063-300 | Cable assembely/PMX85/105/6M/2 wires/integ rated;电缆组/PMX85/105/6M/ 两芯控制线/气电一体 | |
16.3 | IVN02010060-300 | Cable assembely/PMX85/105/6M/2 wires/centre adapter;电缆组/PMX85/105/6M/ 两芯控制线冲央插头 | |
16.4 | IVN02010066-300 | Cable assembely/PMX85/105/6M/4 wires/centre adapter;电缆组/PMX85/105/6M/ 四芯控制线冲央插头 | |
16.5 | IVN0201006C-300 | Cable assembely/PMX85/105/6M/coaxial cable/centre adapter;电缆组/PMX85/105/6M/同轴电缆/中央插头 | |
17 | IZX0078 | Centre adaptor torchside PLASMA 5 PINS;等离子中央插头/5针 |
INWELT PLASMA TORCH CATALOG.pdf
